F19L0CY
1
1. Eyelets
All Models
24) Mooring Cleats
These cleats can be temporarily used
for docking, while refueling for exam-
ple.
F18L0SY
1
TYPICAL
1. Mooring cleats
CAUTION:
Never use mooring
cleats to pull or lift the watercraft.
25) Footboard
User’s feet should rest on the foot-
board when riding.
26) Boarding Pads
Provide a cushioned surface for the
knees when boarding from rear of wa-
tercraft.
27) Boarding Platform
Provides a large surface for easier
boarding from rear of watercraft.
28) Boarding Step
(if so equipped)
A convenient step to help reboarding
the watercraft.
F18L0IY
1
1. Boarding step
Pull down the step with your hand and
hold until a foot or a knee is put on the
step.
F18L0JY
29) Flushing Connector
A convenient connector is provided
to allow easy installation of a garden
hose to flush the exhaust cooling sys-
tem.
_____________________
47
