SeaDoo RXP 4-Tec Supercharged - Drive Shaft Corrosion Protection; Ski;Wakeboard Post (if so equipped); General Inspection and Cleaning

1
F18H0BY
1. Rubber protector
F18H0DY
12
1. Rubber protector
2. Spare fuses
When finished, reinstall the remaining
fuse(s) and reinstall the protector over
fuse(s).
CAUTION:
Do not install more than
4 fuses in cover to allow proper in-
stallation of cover.
Main Fuses
They are located beside the MPEM.
See below for details.
Main Fuse beside MPEM
1
F18H1CY
2
TYPICAL
1. MPEM
2. Main fuse
To remove fuse cover, lift tab then pull
holder out. Pull fuse out using cover
on MPEM as shown above.
F18H1DY
1°
2°
TYPICAL
Reassemble removed parts.
O.P.A.S. System
(if so equipped)
The O.P.A.S. system operation and
condition should be checked by an
authorized Sea-Doo dealer.
96
