WARNING
Certain components in the engine
compartment may be very hot.
Direct contact may result in skin
burn.
Remove seat extension and storage
basket to expose expansion tank.
1
F18E0MY
2
ALL MODELS EXCEPT RXP
1. Expansion tank
2. Cap
F19E01Y
2 1
RXP MODELS
1. Expansion tank
2. Cap
Refer to LIQUIDS for more details.
40) Ski/Wakeboard Post
(if so equipped)
Pull up the post to hook up a ski or
wakeboard rope. Push down when
finished and lock in properly.
To lift post, unlock by pulling the lock-
ing pin then lift post. Ensure it is prop-
erly locked. Lowering the post is the
opposite operation.
2
F18L2ZY
1
1. Ski/wakeboard post
2. Pull locking device to unlock
1
F18L30Y
2
1. Ski/wakeboard post lifted
2. Ensure it is locked
WARNING
Make sure ski/wakeboard post is
fully extended and locked before
use. Completely retract and lock
when not used. Use caution with
skier/wakeboarder in tow as tow
rope may backlash to watercraft
when released. Never perform a
sharpturnwhentowingaskier,
wakeboarderoranytoy.
Always have one person other than
the operator as an observer.
_____________________
53
