Seaga JDL-2 COMBO - Refrigeration System; Refrigeration Deck Access

61JDL V1.0 8 2022
d. Inspect and remove jammed bill.
e. Replace lower unit to resume normal operaon
REFRIGERATION DECK
Your Beverage unit incorporates a high eciency refrigeraon system having two air circulaon fans to chill the
cans and boles. The refrigeraon unit can be easily accessed by opening the beverage unit door and sliding
the front grill up and out. Remove the single blue thumbscrew from the center oor of the refrigeraon deck
and remove the paron wall. Remove the two screws holding the handles in place (Figure 24).
Figure 24 – Refrigeraon deck
Condenser
Gently clean
ns on a regular
basis
Remove three
screws
Compressor
