Figure 3.8
3) Press the OK button to save your selection and return to previous
menu.
Tool Self-test
The Tool Self-test function checks if the display, LED lamps and
keyboard are working properly.
A. Display test
The Display Test function checks if the LCD display is working
normally.
1) From System Setup screen, use the UP/DOWN scroll button to
select Tool Self-test, and press the OK button.
2) Select Display Test from Tool Self-test menu and press the OK
button to start test. (Figure 3.9 )
Figure 3.9
3) Look for missing spots in the red, green, blue, black and white
LCD display.
Status Beep Set 1/2
Beep ON
Beep OFF
?
Tool Self-test 1/3
Display Test
Keyboard Test
LED Test ?
To Next Page
