NOTE: If the door arm is hanging down too far, please cut the extra part from the end.
To avoid possible overheating of the end panel or light socket:
· Use ONLY A19 incandescent or compact fluorescent light bulbs.
· DO NOT use incandescent bulbs larger than 100W.
· DO NOT use compact fluorescent lamp(CFL) larger than 26W (100W) equivalent.
· DO NOT use halogen bulbs.
· DO NOT use short neck or specialty light bulbs.
7.5 After door bracket, door arms and trolley securely fastened, Pull the
emergency release towards the chain/belt connector . Once they are
connected, you will hear a click.
7.3 Line up the straight arm and curved arm. And fasten them using the bolts
(H4), nuts (H3) inserted in the 2 holes as far apart as possible.
7.4 If the curved arm and straight arm’s holes do not exactly match, pull the
emergency release to move the trolley a little bit. The holes should be aligned.
