10.1 Strip back 10 mm of
insulation and separate the wires.
10.2 Open the back cover of the wall
control.
10.3 If the wires are not connected,
Connect the white wire to the #3
screw ,connect the red \white
wire to the #4 screw.
10.4 Mark the location of the 2 holes
of back cover of wall control and
drill a 6 mm hole.
10.6 Snap the wall control
onto the back cover.
5/13” (10mm)
10.5 Insert and tighten screws to
secure the back cover of the
wall control to wall.
