13.1 Install the Photo Eye Sensors(PE-002)
The photo eye sensors can be attached to the wall or the floor, The sensors should
be no more than 6 inches (15 cm) above the floor.
Photo eye Sensor 6”(15cm)
max .above floor
Infrared beam protection area
15cm
1cm
