Seastar Solutions Optimus 360 Operation Manual

11
© 2013 SeaStar Solutions Optimus 360 Joystick Control System, Rev. C
3.0 COMPONENT IDENTIFICATION
The electronic helm is the primary user interface for conventional
steering control. When in conventional steering control, all helms on
the boat are active and can steer the boat.
The steering wheel is attached to the helm, which may be located
immediately under the wheel or just behind the dash panel. The
images below show typical helms.
Refer to Section 4.0 for steering operation.
EPS Front Mount Helm
EPS Classic Tilt Helm
EPS Sport Plus Tilt Helm
EPS Rear Mount Helm
3.1 Electronic Helm(s) (EPS System)
Figure 3-1. EPS Helm configurations.
Keep magnets away from the helm. they may interfere with proper
helm operation.
CAUTION
