61
© 2013 SeaStar Solutions Optimus 360 Joystick Control System, Rev. C
12.0 TROUBLESHOOTING GUIDE
WHENEVER, IN THE FOLLOWING TEXT, A SOLUTION CALLS FOR
REMOVAL FROM VESSEL AND/OR DISMANTLING OF SYSTEM
COMPONENTS, SUCH WORK MUST ONLY BE CARRIED OUT BY A
QUALIFIED MARINE HYDRAULIC MECHANIC. SEASTAR SOLUTIONS
OFFERS THE FOLLOWING AS A GUIDE ONLY AND IS NOT RESPONSIBLE
FOR ANY CONSEQUENCES RESULTING FROM INCORRECT
DISMANTLING REPAIRS.
Optimus 360 will provide years of safe reliable performance with a
minimum of service if properly installed.
Optimus 360 steering systems have been designed with protection
against over-pressure situations, with the inclusion of a pressure
relief valve and circuit breakers, to minimize the possibility of total
loss of steering.
Most faults occur when the installation instructions are not followed
and usually show up immediately upon filling the system. Provided
below, are the most common faults encountered and their likely
cause and solution.
FAULT CAUSE
SOLUTION
Check circuit breaker for the engine.
Batteries not turned ON, or in poor
working condition.
Ignition wires disconnected.
CANtrak connection damaged and/
or not connected.
Tachometer is not relaying
information.
CANtrak NOT writing proper
information.
Reset breaker. If it immediately trips
a second time look for a shorted or
pinched wire or failed component.
Load test batteries.
Confirm all connections are in place.
Inspect wires for damage.
Confirm Tachometer is operating
properly (check connections).
Confirm that your settings have
been saved. If they are not saved,
contact Tech support.
3.
One engine does not
steer, but CANtrak
display is on.
1. CANtrak does not
turn ON?
2. High/Low Speed
wheel turn setting
not working
WARNING
