40
© 2013 SeaStar Solutions Optimus 360 Joystick Control System, Rev. C
After reading the initial warning screen press the INFO button and
follow the prompts for a system inspection.
ON MULTIPLE HELM STATION BOATS ALL STEERING HELMS ARE ACTIVE
WHEN THE OPTIMUS 360 IS TURNED ON. THIS IS THE SAME
YOU
WOULD FIND ON A CONVENTIONAL HYDRAULIC STEERING SYSTEM.
Turning on the ignition switch will turn on the Optimus 360 system.
The CANtrak display will turn on and steering will become active at
all helms.
All Helms Active
Splash Screen
Initial Warning System Check 1 System Check 2
INFO NEXT
3 SEC INTERVAL
BACK
OK
System Check 3
NEXT
OK
BACK
8.2 Initial Start Up
WARNING
Figure 8-3. All Helms Active screen (normal steering mode).
Figure 8-2. CANtrak initial warning screen.
