© 2013 SeaStar Solutions Optimus 360 Joystick Control System, Rev. C
7.4.3 Adjust (ADJ) Screen
*
The Adjust screen allows adjustment of system parameters which
affect steering operation and feel. Specific details of each parameter
are listed below.
Changes made in the Adjust screen are saved to memory upon
exiting the Adjust screen. You will be prompted to save changes
before exiting as shown in the display.
BUTTON
LEGEND
POINTER
BUTTONS
Low Speed Turns
Sets the number of turns (hard-over to hard-over) when the vessel is
running at low speeds. The range is 3.5 to 8 Turns.
High Speed Turns
Sets the number of turns (hard-over to hard-over) when the vessel is
running at high speeds. The range is 3.5 to 8 Turns.
Low Speed Steering Effort
Sets the steering resistance when the vessel is running at low speeds.
It is adjustable between 1 and 100.
High Speed Steering Effort
Sets the steering resistance when the vessel is running at high speeds.
It is adjustable between 1 and 100.
Autopilot Engaged Steering Effort
Sets the steering resistance when autopilot is engaged. To prevent
accidental course corrections with the wheel this should be set slightly
higher than the high speed effort. It is adjustable between 0 and 100.
* Some installations may not have this feature accessible. Contact dealer/builder.
Figure 7-6. Adjust (ADJ) screen.
