21
© 2013 SeaStar Solutions Optimus 360 Joystick Control System, Rev. C
The joystick is the primary user interface for the Joystick Control
System. It offers the ultimate control of the vessel for docking and
maneuvering at slow speeds and is especially useful in confined or
difficult circumstances. It is quite intuitive to use as the boat follows
the actions of the handle. This section of the manual gives a
detailed description of all of its capabilities and how to get the
maximum benefit from this powerful feature. The Optimus 360
Joystick Quick Reference Guide, provided with the system, gives
summary and reminder information on its operation and should be
kept on the vessel at all times.
The joystick is spring loaded so it always returns to its center
position. When the joystick is active and in the center position, the
engines are in neutral and the throttles are at idle.
The joystick Take Command button will make the joystick active when
it is pushed. The shift and throttle controls must be in neutral to
engage the joystick. When the joystick is active, the Take Command
light will be solid blue. Consult Section 5 for transferring control back
to conventional shift and throttle .
While the joystick is active, the turning resistance of the steering
wheel will increase to remind the user that it is disengaged.
The Boost button increases the engine RPM when pressed. It may
be activated any time the joystick is active.
Note: The A and C buttons are reserved for future use and not active
at this time.
6.0 JOYSTICK OPERATION
While the joystick is active the turning resistance of the steering
wheel will increase to remind the user that it is disengaged.
NOTICE
