6.6 Viewing historical data
Pipit receives updated historical data every hour from the Smart Meter. If the unit loses power, or the HAN
connection fails, it will attempt to collect missing data when the power or connection is restored, up to a
maximum of 45 days. Pipit displays historical net electricity consumption data graphically as well as in tabular
form and also allows consumption values to be compared with the previous day, week, month or year.
The History icon from the main menu shown above accesses the following History screen, which has three
further navigation icons as shown below:
The function of the icons on the History screen are summarised in the table below:
Button / Icon Function
Accesses the current day’s net hourly electricity consumption pattern and daily consumption
graph, along with the preset daily target threshold. It can also display daily, weekly and monthly
electricity consumption, cost of consumption ($) and carbon emissions (CO
2
kg) patterns. The
hour and day graph can display data for the most recent 45 days. The weekly and monthly
graph can display data for the most recent 8 weeks and 13 months respectively.
Accesses comparison data for net electricity consumption, cost and carbon emissions between
the current day and yesterday, current week and previous week, current month and previous
month or current year and previous year.
Accesses hourly net electricity consumption, cost or carbon emissions for the current day in
tabular form. It can also display daily, weekly and monthly data tables. The hour and day tables
can display data for the most recent 45 days. The weekly and monthly table can display data
for the most recent 8 weeks and 13 months respectively.
Table 3
Press the appropriate icon to see the desired information screen, or press Menu to return to the main menu.
