7 Annexe-I: Pipit 500 technical specification
Dimension: 115 x 80 x 40 mm
Weight: 0.2 kg
Power consumption: < 0.6 W
Display area: 76 x 40 mm
Display resolution: 240 x 128 pixels
Touch screen: Resistive type
Material: ABS (Acrylonitrile Butadiene Styrene) / PC FR ( Polycarbonate Flame Retardant)
Colour: White (with glossy finish)
Replaceable battery: 2 x AAA-size alkaline non-rechargeable batteries
Memory size: 2 MB
Operating temperature:
-10
C to +50
C
Storage temperature: -20
C to +70
C
Relative humidity: 0 to 95%
Ingress protection: IP40
Operating life: 5 years
8 Annexe-II: Compliance standards and certification
Specification Applicable standard
Compliance mark to be applied for Labelling C-tick
ZigBee® compliance ZigBee Smart Energy In-Premise Display
Safety Standard AS NZS 60950-1
Power supply compliance AS NZS 4665
Conducted emission CISPR 22
Radiated emission CISPR 22
Compliance
Pipit 500 conforms to all the essential requirements of EU Directive 1999/5/EC, WEEE 2002/96/EC and complies
with RoHS.
Follow the local safety norms to dispose off the batteries and the product safely at the end of their life.
