Daylight saving:
For turning the DST (daylight saving time) one-hour offset on or off.
When turned on, the DST one-hour offset will be applied to the local
time displayed in the status bar.
Note: Pipit will hide this option if it receives DST information from the
meter.
Backlight:
For setting the backlight to turn off after one minute or to remain on.
Contrast:
For setting the touch-screen display contrast to minimum, low,
medium or maximum brightness levels. It is set to ‘Min’ at
manufacture.
Lights:
For setting the two indicator lights on or off. When set to ‘On’ the left-
hand indicator light will illuminate green (for ECO), yellow (for MED)
or red (for HIGH) to indicate the current power usage level, whereas
the right-hand indicator light will flash green to notify the receipt of a
message. If set to ‘Off’ both the indicator lights are disabled.
Table 5
Note: With the exception of the Target button, the above described are toggle buttons. Tapping a toggle button
will select the alternate option and the label on the button will show the selected option.
6.7.1.1 Setting consumption target
The Target button from the standard Settings menu allows the daily consumption target to be set. The
threshold can be set from the following screen:
To change the target value tap the number button, labelled with the
current target value (99 in the example above) to access a keypad
on the screen:
Note that the current value is displayed on the right-hand side of
the keypad. Enter the new value and then press OK to set the new
target, or press Cancel to retain the old value and return to the
previous screen.
The Unit selection button is
used to select the unit.
Press this button to cycle
between kWh, $, CO
2
units.
