Insulation test
Preliminary operation
• Insulation test have to be performed after complete and correct functional test of the lift have been
made.
• Position the car between two floors and check that all doors are closed.
• Check that AM circuit breaker (on control panel) is closed.
• Switch off the mains (both power and light supply).
• Remove all yellow/green wires from earth bar, except those connected to metal parts and to earth
disperser.
• Disconnect yellow/green wire from terminal 100, in controller and in car connection box.
• Disconnect yellow/green wire from terminal 100 in the emergency battery drive SEC-3EBD
• Remove connector P8 on SEC-3Q board.
• Remove connector CAL on SEC-3FDR board.
• Remove all connections from inverter (if provided).
• Remove all connections between controllers (if multiplex lift group) and perform complete test
procedure on every single lift.
Insulation measures
By a 500V insulation tester, check resistance values between terminals according following table.
Measured values (in megaOhm) must be higher than 0.5 MΩ.
terminals
POWER
CIRCUIT
M1
M4 (U)
LIGHT
CIRCUIT
LC/L
LV/L
* DOOR
CIRCUIT
MPA/1
ALARM
CIRCUIT
CAL/6
SAFETY
CIRCUIT
SQ1/3
SQ2/9
100
EARTH
(PE)
>0,5
>0,5
>0,5
>0,5
>0,5
* POWER CIRCUIT
M1; M4
>0,5
>0,5
>0,5
>0,5
LIGHT CIRCUIT
LC/L; LV/L
>0,5
>0,5
>0,5
DOOR CIRCUIT
MPA/1
>0,5
>0,5
ALARM CIRCUIT
CAL/6
>0,5
(*) Note: with 230VAC or mains voltage door operator supply do not run the test between
POWER CIRCUIT and DOOR CIRCUIT.
Restore all modified connections when finished.
