HELPY L300 – Telephone dialler
Quick programming
• Set telephone switch to “T” (tone)
Enter programming mode
* 0 #
79 01 # language selection = English
79 07 # language selection = Dutch
Telephone numbers
21 01 1 2 . . . … 1st telephone number … #
21 02 1 2 . . . … 2nd telephone number … #
… … … … …
21 12 1 2 . . . … 12th telephone number … #
Identification code
45 0 # sets immediate link
Automatic answer
64 5 answer after 5 rings
65 9 max. speech time
66 0 telephone network
Elevator identification message
71 01 … talk …
Listen recorded message
72 01 … listen …
Quit programming mode
* 0 #
To restore factory setting:
* 0 # 99
GSM 500-NET unit connection (optional)
Remove connector TEL on battery charger board
SEC-2FDR
• open GSM module and autodialler unit
• place the antenna on GSM module
• install SIM card inside GSM module
• connect GSM module to autodialler by
the supplied cord (schematics, page 13)
• close back GSM module and autodialler
Connect back connector TEL on battery charger
board SEC-2FDR
Use of device
Interphone communication
Lift handset and talk normally to the car.
Active alarm cancelling
* 0 #
Help request from elevator
Answer the call and listen to the elevator
identification message.
0 to talk with the car
5 to repeat identification message
1 to send “help is coming” signal
9 to reset alarm status
Remote-to-car communication
Dial the elevator telephone number
Listen to identification message.
* 0 # 11 to talk with the car
to finish communication
For further instruction on advanced use and programming please refer to Helpy L300.
