Final Limit Switches test
Traditional shaft (magnets and/or motor encoder)
Upper final limit switch FLS:U
• register a call for top floor.
• after deceleration (car at low speed) disconnect SC3 connector on SEC-3S board
• car will continue its run until upper final limit switch
In order to set the lift back in service restore connections, then lower the car below limit switch, then
press and hold Clear for 10 sec.
Lower final limit switch FLS:D
• register a call for bottom floor.
• after deceleration (car at low speed) disconnect SC3 connector on SEC-3S board
• car will continue its run until lower final limit switch
In order to set the lift back in service restore connections, then raise the car above limit switch, then press
and hold Clear for 10 sec.
Absolute shaft (ELGO Limax2)
Upper final limit switch FLS:U
• place the car at the penultimate stop
• enter programming, set parameter 02.19 (Inspection Top) = TEST.
• save and exit.
• on SEC-3Q board set dip-switch SW2/ 1 - DOOR - to ON (a beep will sound in controller and in
car).
• register a call to top floor
• after deceleration car will continue its run until upper final limit switch
In order to set the lift back in service restore parameter 02.19 = NO, restore SW2/ 1 - DOOR - to OFF, then
lower the car below limit switch, then press and hold Clear for 10 sec., then press RESET on SEC-3Q board.
Lower final limit switch FLS:D
• place the car at second stop
• enter programming, set parameter 02.19 (Inspection Top) = TEST.
• save and exit.
• on SEC-3Q board set dip-switch SW2/ 1 - DOOR - to ON (a beep will sound in controller and in
car).
• register a call to bottom floor
• after deceleration car will continue its run until lower final limit switch
In order to set the lift back in service restore parameter 02.19 = NO, restore SW2/ 1 - DOOR - to OFF, then
raise the car above limit switch, then press and hold Clear for 10 sec., then press RESET on SEC-3Q board.
