Securlift Secur3 - Legenda

follows: IM_SEC3_02.01_en.docx
60/70
Legenda
Electrical drawings use the following abbreviations:
DEVICES
abbreviation
description
notes
12:H
HIGH speed valve
12:N
DOWN valve
ABE
ALARM bell
ALM-GER
Gervall UCM supply unit
ALS
ALARM signal at landings (legge 13)
AM
SAFETY circuit braker
AP
Interruttore magneto/termico PAWL DEVICE
ARP
Minicontattore PAWL DEVICE
AUX
BALAUSTRADE contact
BRK
Manual BRAKE lever contact
CAB
Car ALARM button
CEG
Apron bypass contact
CEL
Car EMERGENCY LIGHT
CFE
Emergency Brake opening key switch
CFE
DYNATECH A3 release key switch
CG
Apron contact
CH.
Landing loks supervision contact (additional)
EN 81-21
CL:A
A side door CLOSE contactor
CL:B
B side door CLOSE contactor
CRA
Door open braking contact
CRC
Door close braking contact
CSD1
Bistable sensor for down transit speed check
CSU1
Bistable sensor for up transit speed check
DBY
BYPASS switch
DCB
DOOR CLOSE button
DOB
DOOR OPEN button
DP
Minicontattore blocco Alta Velocità Discesa
DSV
Bucher DSV-A3 valve
DZI
CAR AT FLOOR signal
DZSM
Door Zone Safety Module
EA
HIGH speed valve
EB
DOWN – LOW speed valve
EBD H
Dispositivo emergenza x oleo
EBD T
Dispositivo emergenza x fune
EME
Segnalazione IN EMERGENZA
EMM
Emergency contactor
EMM
Mains/Emergency swap contactor – for SEC-3SULLY board
ESS
SOFT STOP valve
EU
Landing locks control device
EN 81-21
EU
Braker and release coil for landing locks control device
F..
Fuses
FAN
FAN command
FCA1
Fine corsa addizionale
EN 81-21
