Securlift Secur3 - Run Time Supervision Test; Overspeed Governor Remote Test

follows: IM_SEC3_02.01_en.docx
23/70
Run Time Supervision test
Hydraulic lift
• manually block the car movement (e.g. disconnect vanes, close oil tap, disconnect power unit)
• register a call
• car doesn’t move, and after the set time in 01.07 display shows Run Time Superv.
• system goes OSS (Out of service)
In order to set the lift back in service restore connections, restore original value in parameter 01.07, press
and hold Clear for 10 sec.
Traction lift
• enter programming mode and set parameter 01.07 = 20 sec.; exit and save modification
with FUJI inverter
with VACON inverter
• set in Fuji inverter parameters C10 e C11 at
0.00Hz
• set in Vacon inverter parameters P.2.2.7
and P2.2.11 at 0.00Hz)
• register a call and, after starting, remove SC3 connector on SEC-3S board
• car doesn’t move, and after the set time in 01.07 display shows Run Time Superv.
• system goes OSS (Out of service)
In order to set the lift back in service restore original value in the inverter, then press and hold Clear for
10 sec.
Overspeed governor remote test.
Test instruction
• insert TEST shunt in OST connector
• register a call
• after starting press TEST button; the remote test coil will be energized and the governor will trip.
Reset instruction
• if governor has a reset coil, insert RESET connector in OST connector and press TEST button
• move the car toward opposite direction to restore the safety gear, by using the RDF function
