Tests of the A3 device with Door Zone Safety Module (DZSM)
In order to test the correct operation of the safety device against uncontrolled movement an “A3 test kit”
is provided. It operates on the safety circuit and simulates the opening of the landing doors outside the
unlocking zone (test applicable only with the DZSM safety module).
CONDITIONS TO START THE TEST: ELEVATOR INSTALLED AND WORKING CORRECTLY
TEST INSTRUCTION:
1. Register a call by the SEC-3KBD keypad
2. Wait for the standby condition, i.e. the system is stationary with closed doors (led 1 2 3 4 5 6 lit
on board SEC-3S)
3. Open the AM switch (to remove voltage from the safety circuit)
4. CONNECT THE A3 TEST KIT PROVIDED BY SECURLIFT
5. Set parameter 02.33 to "TEST”
6. Close the AM switch
7. Register a call by the SEC-3KBD keypad
8. The elevator starts moving and the controller sets the nominal speed
9. IF THE SAFETY SYSTEM WORKS CORRECTLY, THE ELEVATOR STARTS MOVING AND IS BLOCKED AS
SOON AS IT LEAVES THE DOOR UNLOCKING ZONE.
10. Open the landing door by the emergency key and check the movement carried out by the car
11. To reset the system in working condition:
a. close the landing door
b. remove the A3 test kit
c. restore the original connections
d. press for 5 sec the Clear button on the SEC-3KDB keypad
e. Return the parameter 02.33 to "Yes"
f. press the RESET button on the SEC-3Q main board
NOTE: The test system provided by SECURLIFT maintains the same safety level of the normal operating
condition. The speed of the system reached at the moment you open the security contact depends on the
speed reached by the car, and therefore by the acceleration that occurs in the 20cm of floor zone.
The speed programmed for the A3 test is the same as the one set during normal operation.
The test must be performed prior to first installation of the system, and during periodic checks.
