C12 (various I/O)
1 IN1 input door motor temperature
2 IN2 input car doors closed while Bypass
3 IN3 future use
4 IN4 future use
5 OUT1 FIRE fire/fireman’s
6 OUT2 PRL Landing priority
7 OUT3 ALF Alarm filter – Easy Alarm
8 OUT4 DBYBYPASS active
9 +24 VDC
10 GND
CAN1IN (serial link to controller – SEC-3Q)
1 CH – CAN high
2 CL – CAN low
3 +24 VDC
4 GND
5 +24VDC
6 GND
LED’s which are monitoring relay are connected in series to the relay coil.
