follows: IM_SEC3_02.01_en.docx
47/70
Connectors
CT9
1 O_EME In Emergency output
OVR Overload
2 O_GNG aux. Gong output
3 FRD2 2
nd
Fireman’s key NC
4 IN calls disable input
5 +24 VDC
6 GND
CT10
1 UPD: UP direction arrow
2 DND: DOWN direction arrow
3 +24 VDC
4 GND
CT11 (uscite posizione cabina)
1 a segment a bin 1 dec 1
st
floor
2 b segment b bin 2 dec 2
nd
floor
3 c segment c bin 4 dec 3
rd
floor
4 d segment d bin 8 dec 4
th
floor
5 e segment e bin 16 dec 5
th
floor
6 f segment f bin 32 dec 6
th
floor
7 g segment g dec 7
th
floor
8 O_OVR overload output (with 7 segmenti
Minus symbol) dec 8
th
floor
9 +24 VDC
10 GND
CT4
1 door open
2 door close
3 +12VDC
4 +12VDC
5 emergency light
6 alarm button
7 intercom + (alarm sent)
8 intercom –
9 +12VDC
10 -12VDC
CT8 (options)
1 FRD Fireman’s key switch
2 STOP & OSS: STOP/OSS input
3 PRC Car Priority key switch
4 O_FIRE Fire/Fireman’s output
5 OSI Out of Service output
6 O_PRC Priority call output
7 +24VDC
8 GND
CT3 (ISE inputs)
1 intercom + (alarm sent)
2 intercom –
3 alarm button
4 luce emergenza
5 alarm received +12V
6 //not used//
7 +12VDC
8 -12VDC
BST LCD interface
1 TX OUT
2 RX IN future use
3 +24VDC
4 GND
CT6
1 +12VDC
2 alarm sent
3 alarm received
4 -12VDC
CAN1 IN (serial link to SEC-3C)
GRAPHIC DISPLAY interface
Future use
PX1 & PX2
(car calls IN-OUT)
PX1: 1-8 floors side A
PX2: 9-16 floor side A
Or 1-8 floor side B
