Securlift Secur3 - Page 49

follows: IM_SEC3_02.01_en.docx
49/70
PX (smoke detector - dip 3 ON)
1  floor 1
2  floor 2
3  floor 3
4  floor 4
5  floor 5
6  floor 6
7  floor 7
8  floor 8
9 +24 VDC
10 GND common
PX (smoke detector - dip 3+1 ON)
1  floor 9
2  floor 10
3  floor 11
4  floor 12
5  floor 13
6  floor 14
7  floor 15
8  floor 16
9 +24 VDC
10 GND common
PX (smoke detector - dip 3+2 ON)
1  floor 17
2  floor 18
3  floor 19
4  floor 20
5  floor 21
6  floor 22
7  floor 23
8  floor 24
9 +24 VDC
10 GND common
