Connectors
DZI (car at floor indicazion)
1 +  positive LED out
2 -  negative LED out
ALC (alarm output)
1 ALC alarm output N.O.
2 ALC
ALB (machinery alarm button)
1 PH A alarm button N.O.
2 +12 VDC
ISE (machinery intercom)
1 ISE/1 intercom 1
2 ISE/2 intercom 2
3 +12VDC
4 -12 VDC
ALB (pit alarm button)
1 PH A alarm button NO
2 +12 VDC
ISE (pit intercom)
1 ISE/1 intercom 1
2 ISE/2 intercom 2
3 +12VDC
4 -12 VDC
ALB (lobby alarm button)
1 PH A alarm button NO
2 +12 VDC
ISE (lobby intercom)
1 ISE/1 intercom 1
2 ISE/2 intercom 2
3 +12VDC
4 -12 VDC
TEL (combinatore telefonico)
1 TEL/1 intercom 1
2 TEL/2 intercom 2
3 alarm output NO
4 “ “
5 +12VDC autodialer supply
6 -12 VDC
SAL (shaft alarm wiring)
1 ABE alarm bell
2 -12 VDC “
3 ALI alarm signalisation at landings
4 -12 VDC “
5 +12VDC
6 -12 VDC
CAL (car alarm wiring)
1 ISE/1 intercom 1
2 ISE/2 intercom 2
3 CAB alarm button NO
4 CEL emergency light
5 IM car at floor sensor NO
6 +12 VDC
7 +12 VDC
8 -12 VDC
OCL (car light)
1 OCL/1 NEUTRAL car ligh
2
3 OCL/3 LIVE - automatic car light
4 OCL/4 LIVE - permanent car light
LR (car light relay pre-wiring)
1 LR/1 RLC relay contavt NC
2 LR/2 “ “
LC (230 VAC supply)
1 LC/1 NEUTRAL
2
3 LC/3 LIVE 230 VAC
