Securlift Secur3 - Page 64

follows: IM_SEC3_02.01_en.docx
64/70
THR
Thermal relay
THR:H
Thermal relay for high speed winding
THR:L
Thermal relay for low speed winding
TINSP
Inspection contactor
TKAK
Minicontattore controllo modulo FIA
TKAK
FIA module contact
TMP
SOFT STOP contactor
TP
Door transformer
TPT
3phase retiring ramp contactor
TR
Re-levelling contactor
TRA
Trasformatore alimentazione PAWL DEVICE
TRC
Trasformatore alimentazione centralina Moris
TRD
DOMINO Transformer
TRF
BRAKE transformer
TRG
Gervall UCM transformer
TRM
Main transformer
TRP
Door transformer
TSD
Contattore SICUREZZE STATICHE
TV
Cooling transformer
TVM
SOFT STOP contactor
UCM-100
GERVALL safety module
VD
DOWN valve
VD2
A3 DOWN valve
VH
HIGH speed valve
VHD
DOWN – HIGH speed valve
VHU
UP – HIGH speed valve
VLD
DOWN – LOW speed valve
VLU
UP – LOW speed valve
VMD
DOWN valve
VML
Levelling valve
VMP
SOFT STOP valve
VST
STAR/DELTA valve; or START valve; or SOFT STOP valve
VU
UP valve
VU/D
UP/DOWN valve
X
Buffer contact
Car connectors
abbreviation
description
note
CPC
Car door contact
CAN1 IN
Controller-Car serial connection
FPA
A door braking
FPB
B door braking
ISE
Car Intercom – Alarm button – Emergency Light – Elarm Received
signal
LKP
Car Locking device
MPA
A door supply
MPB
B door supply
OCL
Car light/fan supply
PT
Retiring ramp
