6. Select “Crystal frequency” at 4MHz.
7. Select COM port according to interface cable installation.
SEC-2L board = MB90F497/G
SEC-3Q board = MB96F338R/U/Y
SEC-3C board = MB90F345A/CA/AS/CAS
SEC-3TRG board= MB90F345A/CA/AS/CAS
SEC-3IO board= MB90F362E/ES/TES
Select “Crystal
Frequency” a 4MHz.
Set COM1 port
Set COM1 port
Select COM port
