Sedecal X - SECTION 4 ADJUSTMENTS; Adjustment Tools and Balance Tests

Universal Radiographic System
Service Manual
SM-0524R4
15
SECTION 4 ADJUSTMENTS
4.1 ADJUSTMENT TOOLS
The following special Tools are commonly used for adjustment of the Rad
Room:
• Collimator Test Tool (Model RMI 161B).
• Beam Alignment Test Tool (Model RMI 162A).
• SID Test Stand Tool (Inside Case -- Model RMI 175).
• Light Meter (Standard).
• Dynamometer.
These tools are not included with the System. Use the
suggested tools or equivalent.
4.2 BALANCE TEST OF THE SWIVEL ARM AND CENTRAL CARRIAGE
This section only applies to syst ems where the X-ray Tube or t he
Collimator has to be replaced by a new different X-ray Tube or
Collimator (different weight).
Note .
Note .
