Universal Radiographic System
Service Manual
SM-0524R4
23
4.4 ALIGNMENT OF X-RAY BEAM
1. Place the Swivel Arm in vertical position. The Tube-Collimator Assembly
has to be perfectly aligned with the Bucky Assembly. Check with a level
correct horizontal position of both assemblies.
2. Place SID at 1 meter.
Illustration 4 -6
Vertical Position of Swivel Arm with Alignment Tools
