5.2 ELECTRICAL CHECKS
ELECTRICAL CHECKS
ELECTRICAL CABLES
AND CONNECTIONS
Check that all electrical connections are firm and secure and that all cable clamps and
strain reliefs are in place. Also check that connectors do not have exposed wires and
check cable sheaths for wear and fraying.
Check that all cables are correctly routed.
5.3 MECHANICAL CHECKS
MECHANICAL CHECKS
MOVEMENT COMPONENTS Check correct operation of the controls, detents, limits and movements in all possible
positions.
STEEL CABLE Verify that the steel cable is in good condition and appearance. Replace the Cable if any
steel wire is damaged.
RAILS Clean the Column Rails with a cloth moistened in clean water and lubricate both rails
with moisten cloth with lubricant oil.
In case of noise during movement, clean and lubricate again.
CHAINS / GUIDES / BEARINGS Clean and lubricate these type of components.
BRAKES / LOCKS Check correct operation of the Brakes / Locks.
Replace if necessary.
FUNCTIONAL CHECKS / ADJUSTMENTS Perform a Functional Check of all Room equipment.
Perform the respective adjustments of the equipment if necessary.
Adjust the motorized movements of the Swivel Arm if required (refer to Section 4.3)
