6. Check on the processed film the adjustment required to meet the Light
Field with the X-ray Field. Identify the deviation on the axes imaged on
the film.
PROCESSED FILM
PROCESSED FILM
COLLIMATED LIGHT FIELD
COLLIMATED X-RAY FIELD
LIGHT FIELD MISALIGNMENT
GOOD FIELDS ALIGNMENT
COLLIMATED LIGHT FIELD = COLLIMA TED X-RAY FIELD
