Universal Radiographic System
Service Manual
SM-0524R4
48
ITEM DESCRIPTION QTY REFERENCE REMARKS
B0 CENTRAL CARRIAGE + ARM
B1 Lower Side Bearing Kit 2 SAT--A9811--01
B2 Concentric Bearing Kit 6 SAT--51501110 each kit includes 2 bearings
B3 Eccentric Bearing Kit 6 SAT--A9812--01 each kit includes 2 bearings
B4 Spring Kit 1 SAT--S02.03.006 includes 4 springs
B5 Brake Plate 1 SAT--S02.03.001
B6 Turn Bearing Kit 1 SAT--A9813--01
B7 Turn Solenoid Kit 1 SAT--A9814--01
B8 Rota tion Spring 1 SAT--S02.04.023
B9 Chain Kit 1 SAT--A9815--01
B10 Pulley Block Kit 1 SA T--A9837--01
B11 Solenoid SID 1 SAT--52301008
B12 Gear Kit 1 SAT--A9827--01
B13 SID Carriage Bearing Kit 4 SAT--A9828--01
B14 Carriage Limit Kit 1 SA T--6533--01 includes 4 bumpers
B15 Console Assembly 1 SAT--S02.10.000
B16 Button Switch 7 SAT--50613013
B17 Brake Kit 1 SA T--A9816--01
B18 Hand Brake Handle Kit 1 SAT--54402008
B19 Inclinometer 2 SAT--10501--01
B20 Handgrip Kit 1 SAT--S02.05.000
B21 Handle 4 SAT--50205012
B22 Tube--Collimator Assembly Turn Kit 1 A520170--01
B23 Bucky Assembly Brake Handle Kit 1 SAT--54402007
B24 Table Top 1 A520312--01
B25 Profile 2 SA T--8952--01
B26 Bucky Drawer 1 A523001--01
B27 Central Gear Kit 1 A520171--01
B28 Bucky 1 SAT--6685--11
B29 Ion Chamber 1 SAT--6695--21
B30 Grid 1 SAT--6697--03
B31 Tube Fan 1 SA T--53103020 Option
B32 Collimator 1 SAT--6693--XX Depends on Collimator installed
B33 Tube 1 SAT--6690--XX Depends on Tube installed
To Next Page
