Universal Radiographic System
Service Manual
SM-0524R4
58
ITEM DESCRIPTION QTY REFERENCE REMARKS
B0 CENTRAL CARRIAGE + ARM
B1 Lower Side Bearing Kit 2 SAT--A9811--01
B2 Concentric Bearing 6 SAT--51501110 each kit includes 2 bearings
B3 Eccentric Bearing Kit 6 SAT--A9812--01 each kit includes 2 bearings
B4 Spring Kit 1 SAT--S02.03.006 includes 4 springs
B5 Brake Plate 1 SAT--S02.03.001
B6 Turn Bearing Kit 1 SAT--A9813--01
B7 Microswitch 1 SAT--50605014
B8 Level Kit 1 SAT--A9824--01
B9 Turn Solenoid Kit 1 SAT--A9814--01
B10 Turn Lock Kit 1 SAT--A9825--01
B11 Rotation Spring 1 SA T--S02.04.023
B12 Arm Chain Kit 1 SAT--A9815--01
B13 SID Motor Kit 1 SAT--A9826--01
B14 Gear Kit 1 SAT--A9827--01
B15 Kit Rodamientos Carro SID 1 SA T--A9828--01
B16 Carriage Limit Kit 1 SA T--6533--01 includes 4 bumpers
B17 SID Microswitch Kit 1 SA T--A9829--01
B18 Console Assembly 1 SAT--S03.10.000
B19 Optima URS Motorized Display 1 SAT--A3195--01
B20 Button Switch 7 SAT--50613013
B21 Brake Kit 1 SA T--A9816--01
B22 Hand Brake Handle Kit 1 SAT--54402008
B23 Inclinometer 2 SAT--10501--01
B24 Handgrip Kit 1 SAT--S03.05.000
B25 Handle 4 SAT--50205012
B26 Tube--Collimator Assembly Turn Kit 1 A520170--01
B27 Bucky Assembly Brake Handle Kit 1 SAT--54402007
B28 Table Top 1 A520312--01
B29 Profile 2 SA T--8952--01
B30 Bucky Drawer 1 A523001--01
B31 Central Gear Kit 1 A520171--01
