SEDECAL
US X--RAY BUCKY INTERFACE
I/F--045
Interconnection Cable
NAME DATE
DRAWING
REVISED
SHEET / OF
AREV
F. GARCIA 08/08/01
2/2
A. DIAZ 08/08/01
REV DESCRIPTION ISSUED BY DATE
Cable de Inerconexión
TS1--12
BUCKY 2 MOTION
INTERFACE PANEL
GENERATOR POWER MODULEVERTICAL BUCKY
TS1--13
BUCKY 2 MOTION RTN
TS1--11
BUCKY 2 DR
Interface Control Board
+24 VDC
K3
BUCKY EXP
+24 VDC
BUCKY 2
DR CMD
K4
K4
K4
J4--10
J4 --7
TS1--10
220 VAC
0VAC
J4 --9
B2
B1
B3
B8
B4
EXP INT
BUCKY START
Bucky
BUCKY SPLY
TS1--9
ADD JUMPER
GND
0VAC
NOTA :
NOTE :
TS1--26
C2
R2
SEE
NOTE
En caso de ruidos debido al Bucky, añadir R2=22 ohm, 1/2w, 5%, y
C2=470 nF, 250 VAC según se muestra.
In the c ase of noise due to Bucky, add R2=22 ohm, 1/2w, 5%; and
C2=470 nF, 250 VAC as shown.
US X--RAY
220 VAC
B6
4
2
1
7
8
A Interf bd. revised
F. G a r cí a
14/03/08
