8. REQUIRED TOOLS FOR INSTALLATION
TOOL
1.5mm Allen Key
To adjust locking screw
on the FFC
Laptop
Installation and
Maintenance functions
(Windows7, Windows8,
Windows10 or Apple
OS are preferred)
Laptop must have an
ethernet port or a USB
port
Protractor / Smart
Phone app
(In degrees)
Determining camera
Pitch and Yaw settings
Box containing the following items:
• (2058/S26 Ratchet Socket Bit Set 26-
Piece)
• 1/4in female bit ratchet
Contents:
Phillips bits: PH-1, PH-2, PH-3
Pozidriv bits: PZ-1, PZ-2, PZ-3
Security Torx bits: T10-security, T15,
T20, T25, T30
Hexagon bits: 3, 4, 5, 6
Slotted bits: 4, 5, 6
Sockets: 6, 7, 8, 10, 13 mm
1- bit holder
1- bit ratchet
1- socket driver 1/4in square male to
1/4in hexagon male
