Guardian Field Support Manual – Section 2
42
5.4.7 VIBRATION MOTOR INSTALLATION
Mounting Location:
The Vibration Motor must be mounted on the
driver’s seat. It must be located above the
adjustment rails and within the red dotted
lines as per the image.
Do not drill the vibration motor to the seat or
frame. This may damage the structural
integrity of the seat. The Motor is to be
mounted using the bracket supplied.
Note: We recommend that you do not
mount the Vibration Motor under the sliding
adjustment rails as the vibration cannot be
easily felt by the driver.
The placement of the Vibration Motor must
not interfere with the seat belt, or seat
adjustment functions. It should also not be
mounted in such in way that it interferes with
the driver’s comfort and safety.
Note: If the Vibration Motor can only be
mounted outside of the red dotted line, you
must seek approval from the site
representative.
Locate a flat, round or square bar.
