Guardian Field Support Manual – Section 2
58
6.1 APPLYING LATEST SOFTWARE TO THE CONTROLLER
The Software (SW) Installation is to be conducted once you have completed installing all the
Hardware components. As the system needs to be configured, all components (except for the
processor) need to be in their final location.
You will upload the SW using a USB Recovery Dongle (refer to Section 3.5).
The latest version of the SW will be available via the TCP in the Knowledge Base. Certified
Installers can navigate to Guardian Generation 2 > Gen 2 Downloads/Forms where the
Recovery Dongle Creator and SW release notes will be found.
Un-isolate the vehicle and ensure the
ignition is ‘off’.
Insert the USB Recovery Dongle into the
USB port on the Controller.
Turn the ignition to ‘On’. The Controller will
now power up and commence applying the
SW.
