Guardian Field Support Manual – Section 2
55
5.4.10 CABLING INSTALLATION
Mounting Location:
When installing the cabling, ensure you have
enough length, with slack, to reach the
Controller.
Placement of cables:
After all components have been installed
and the cable routed correctly, the cables
returning to the Controller should be fixed for
easy access when the Controller is removed
from the Mounting Pan.
Cable relief:
After all cables have been plugged into the
Controller, the cable relief management
system must be used. This will minimise pull
on the cables and allow easy removal of the
Controller Cover.
