Guardian Field Support Manual – Section 2
38
5.4.5 3/4G ANTENNA INSTALLATION
Mounting Location:
The 3/4G antenna must be mounted so that there is a clear line of sight to the sky.
The 3/4G antenna can transmit through plastic, wood and fiberglass.
It cannot transmit through metal.
It is recommended that you mount the antenna as close to a window as possible. The shape of
the antenna allows you to mount it close to the windscreen.
Mount the 3/4G antenna at least 30cm from
the GPS Antenna.
Mount the 3/4G antenna at least 60cm from
the ICS and any other antennas, such as 3
rd
party GPS systems and communication
antennas
Mount the antenna at least 1m from the
Controller.
Types of Mounting:
The 3/4G Antenna comes with adheisive
tape for mounting.
You must clean the area with the provided
alcohol wipe and allow it dry for 1 minute
before mounting.
Ensure you firmly press down on the
Antenna for 30 seconds.
Important Points to Note:
