Seg WI Series Reference Manual

Baud rate Description
19200 19200
38400 38400
Physical Settings
Digit 1: Number of bits. Digit 2: E=even parity, O=odd parity, N=no parity. Digit 3: Number
of stop bits. More information on the parity: It is possible that the last data bit is followed by a
parity bit which is used for recognition of communication errors. The parity bit ensures that
with even parity ("EVEN") always an even number of bits with valence "1" or with odd parity
("ODD") an odd number of "1" valence bits are transmitted. But it is also possible to transmit
no parity bits (here the setting is "Parity = None"). More information on the stop-bits: The
end of a data byte is terminated by the stop-bits.
Selection list referenced by the following parameters:
• ╚═▷ Modbus . Physical Settings•
Physical Settings Description
8E1 8 data bits, even parity, 1 stopbit.
8O1 8 data bits, odd, 1 stopbit.
8N1 8 data bits, no parity, 1 stopbit.
8N2 8 data bits, no parity, 2 stopbits.
Phase Sequence
Selection list referenced by the following parameters:
• ╚═▷ CT . Phase Sequence•
Phase Sequence Description
ABC Clockwise Rotating Field (“ABC” = “L1-L2-L3”)
ACB Anti-Clockwise Rotating Field (“ACB” = “L1-L3-L2”)
fN
Selection list referenced by the following parameters:
• ╚═▷ CT . f•
136 WIC1 WIC1-2.0-EN-REF
