Seg WI Series Reference Manual

9.8 I> – Phase Overcurrent Stage
9.8.1
I>: Device Planning Parameters
I> . Mode [Device planning / Projected Elements]
use “-”, use
╚═▷ Device planning
P.1
Phase Overcurrent Stage, general operation mode
I> . De󰈛nition [Device planning / De󰊟nition]
Trip Trip, Alarm
╚═▷ De󰊟nition
P.1
Phase Overcurrent Stage: If set to “Alarm”: The function operates as a supervision function, i.e. a fault generates
neither alarm nor trip, but an »Alarm« signal gets issued instead. If set to “Trip”: The function operates as a
protection function, i.e. trips the breaker in case of a fault.
9.8.2
I>: Settings
I> . Function [Protection Para / I>]
Active Inactive, Active
╚═▷ Mode
P.1
Permanent activation or deactivation of module/stage.
50 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.8 I> – Phase Overcurrent Stage
