Seg WI Series Reference Manual

9.22 Supervision
9.22.1
TCM – Trip Circuit Monitoring
9.22.1.1 TCM: Device Planning Parameters
TCM . Mode [Device planning / Projected Elements]
use “-”, use
╚═▷ Device planning
P.1
Trip Circuit Supervision, general operation mode
9.22.1.2 TCM: Settings
TCM . Function [Protection Para / TCM]
Inactive, Active
╚═▷ Mode
P.1
Permanent activation or deactivation of module/stage.
TCM . ExBlo [Protection Para / TCM]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
9.22.1.3 TCM: Input States
TCM . ExBlo-I [Operation / Status Display / TCM]
Module input state: External blocking
9.22.1.4
TCM: Signals (Output States)
TCM . Active [Operation / Status Display / All Actives]
[Operation / Status Display / TCM]
Signal: active
