Seg WI Series Reference Manual

IG> . IH2 Blo [Protection Para / IG>]
If: IH2 . Mode = use
• Inactive, Active•
If: IH2 . Mode = “-”
• Inactive•
╚═▷ Mode
P.1
Blocking the trip command, if an inrush is detected.
IG> . Stab. by CLPU [Protection Para / IG>]
Inactive
Only available if:
• CLPU . Mode = use•
Inactive, Active
╚═▷ Mode
P.1
Select whether the CLPU stabilization shall be e󰅯ective for this protection stage. (If set to “active” then further
settings are available within the CLPU menu.)
IG> . ExBlo [Protection Para / IG>]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
9.11.3
IG>: Input States
IG> . ExBlo-I [Operation / Status Display / IG>]
Module input state: External blocking
9.11.4
IG>: Signals (Output States)
IG> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / IG>]
Signal: active
IG> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / IG>]
Only available if:
• IG> . De󰊟nition = Trip•
Signal: Trip
76 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.11.3 IG>: Input States
