7.1 Peak Current Ptr – Statistic of the current measuring values
7.1.1
Peak Current Ptr: Settings
Peak Current Ptr . Time win. for calc. avg. [Protection Para / Condition Monitoring / Peak Current Ptr]
15 min 1 min, 8 min, 15 min, 20 min
╚═▷ Time win. for calc. avg.
P.1
Select the time-window for calculating average values
7.1.2 Peak Current Ptr: Direct Controls
Peak Current Ptr . Clear [Operation / Reset]
Inactive Inactive, Active
╚═▷ Mode
P.1
Direct Command to reset the drag indicator for »Imax«
7.1.3
Peak Current Ptr: Values
Peak Current Ptr . Imax [Operation / Condition Monitoring / Peak Current Ptr (Val.)]
Maximum value of the averaged phase current »Iavg« since the last reset
Peak Current Ptr . Iavg [Operation / Condition Monitoring / Peak Current Ptr (Val.)]
Maximum value of the phase current, time-averaged over the set time-window
As long as the displayed value of »Iavg« is not signi󰅰cant yet, because the calculation is ongoing, the value is
displayed as “-0.0”. (After the set time window has elapsed a valid value is displayed.)
31WIC1WIC1-2.0-EN-REF
7 Statistics
7.1 Peak Current Ptr – Statistic of the current measuring values
