Seg WI Series Reference Manual

2.2 DiggiMEC
2.2.1
DiggiMEC: Device Planning Parameters
DiggiMEC . Mode [Device planning / WIC1 + DiggiMEC]
“-”, DiggiMEC-A, DiggiMEC-B
╚═▷ Device planning
P.1
DiggiMEC, general operation mode
2.2.2 DiggiMEC: Settings
DiggiMEC . Menu language [Device Para / DiggiMEC / General Settings]
English English
╚═▷ My Language
P.1
Selection of the language
DiggiMEC . Operation Preference [Device Para / DiggiMEC / General Settings]
Precise meas. Precise meas., Early wake-up
╚═▷ Operation Preference
P.1
If set to “Early wake-up”, the DiggiMEC is fully available at smaller primary currents, but at the cost of more
inaccurate WIC1 measurement values. If set to “Precise meas.”, the DiggiMEC gets fully available only with higher
primary currents, but the WIC1 measurement values will be more precise. In general, it is recommended to keep the
default “Precise meas.”.
DiggiMEC . FI / BO 1 assign. [Device Para / DiggiMEC / FI / BO]
Prot . TripCmd
Only available if:
• DiggiMEC . Mode = DiggiMEC-B•
“-” . . . Prot . Pos OFF
╚═▷
P.1
Assignment of the Flag Indicator / bistable output relay
DiggiMEC . FI / BO 1 latching [Device Para / DiggiMEC / FI / BO]
Latch. w. Auto-Reset
Only available if:
• DiggiMEC . Mode = DiggiMEC-B•
No latching, With latching, Latch. w. Auto-Reset
╚═▷ Latching
P.1
De󰅰nes whether the Flag Indicator/output relay will be latched when it is set. In case it is set as latched then you also
have a choice between several automatical reset modes.
13WIC1WIC1-2.0-EN-REF
2 Hardware
2.2 DiggiMEC
