DiggiMEC . FI / BO 2 assign. [Device Para / DiggiMEC / FI / BO]
Prot . Trip IPh “-” . . . Prot . Pos OFF
╚═▷
P.1
Assignment of the Flag Indicator / bistable output relay
DiggiMEC . FI / BO 2 latching [Device Para / DiggiMEC / FI / BO]
Latch. w. Auto-Reset No latching, With latching, Latch. w. Auto-Reset
╚═▷ Latching
P.1
De󰅰nes whether the Flag Indicator/output relay will be latched when it is set. In case it is set as latched then you also
have a choice between several automatical reset modes.
DiggiMEC . FI / BO 3 assign. [Device Para / DiggiMEC / FI / BO]
Prot . Trip IG
Only available if:
• DiggiMEC . Mode = DiggiMEC-B•
“-” . . . Prot . Pos OFF
╚═▷
P.1
Assignment of the Flag Indicator / bistable output relay
DiggiMEC . FI / BO 3 latching [Device Para / DiggiMEC / FI / BO]
Latch. w. Auto-Reset
Only available if:
• DiggiMEC . Mode = DiggiMEC-B•
No latching, With latching, Latch. w. Auto-Reset
╚═▷ Latching
P.1
De󰅰nes whether the Flag Indicator/output relay will be latched when it is set. In case it is set as latched then you also
have a choice between several automatical reset modes.
DiggiMEC . LED2 assign. [Device Para / DiggiMEC / LEDs]
TCM . Alarm “-” . . . Prot . Pos OFF
╚═▷
P.1
Assignment of the LED 2
DiggiMEC . LED2 Color
DiggiMEC . LED3 Color
[Device Para / DiggiMEC / LEDs]
Red Red, Green, Green / Red
╚═▷ Color
P.1
Select the “active” color (if the assigned signal is active) and the “inactive” color (if the assigned signal is inactive)
14 WIC1 WIC1-2.0-EN-REF
2 Hardware
2.2.2 DiggiMEC: Settings
