Seg WI Series - I2>: Input States; I2>: Signals (Output States)

I2> . IH2 Blo [Protection Para / I2>]
Active If: IH2 . Mode = use
• Inactive, Active•
If: IH2 . Mode = “-”
• Inactive•
╚═▷ Mode
P.1
Blocking the trip command, if an inrush is detected.
I2> . ExBlo [Protection Para / I2>]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
9.14.3
I2>: Input States
I2> . ExBlo-I [Operation / Status Display / I2>]
Module input state: External blocking
9.14.4
I2>: Signals (Output States)
I2> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / I2>]
Signal: active
I2> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / I2>]
Only available if:
• I2> . De󰊟nition = Trip•
Signal: Trip
I2> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / I2>]
Only available if:
• I2> . De󰊟nition = Alarm•
Signal: Alarm
91WIC1WIC1-2.0-EN-REF
9 Protection Parameter
9.14.3 I2>: Input States
