Seg WI Series - I>>: Input States; I>>: Signals (Output States)

I>> . IH2 Blo [Protection Para / I>>]
Active If: IH2 . Mode = use
• Inactive, Active•
If: IH2 . Mode = “-”
• Inactive•
╚═▷ Mode
P.1
Blocking the trip command, if an inrush is detected.
I>> . Stab. by CLPU [Protection Para / I>>]
Inactive
Only available if:
• CLPU . Mode = use•
Inactive, Active
╚═▷ Mode
P.1
Select whether the CLPU stabilization shall be e󰅯ective for this protection stage. (If set to “active” then further
settings are available within the CLPU menu.)
I>> . ExBlo [Protection Para / I>>]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
9.9.3
I>>: Input States
I>> . ExBlo-I [Operation / Status Display / I>>]
Module input state: External blocking
9.9.4
I>>: Signals (Output States)
I>> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / I>>]
Signal: active
I>> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Trip•
Signal: Trip
61WIC1WIC1-2.0-EN-REF
9 Protection Parameter
9.9.3 I>>: Input States
