Seg WI Series Reference Manual

7.2 Life Load – Load Current Histogram
7.2.1
Life Load: Device Planning Parameters
Life Load . Mode [Device planning / Projected Elements]
use “-”, use
╚═▷ Device planning
P.1
Load Current Histogram, general operation mode
7.2.2 Life Load: Settings
Life Load . Function [Protection Para / Condition Monitoring / Life Load]
Inactive Inactive, Active
╚═▷ Mode
P.1
Permanent activation or deactivation of module/stage.
Life Load . I [Protection Para / Condition Monitoring / Life Load]
> 1.0 In In > 0.4 In In . . . > 1.2 In In
╚═▷ I
P.1
The sum of operating times in current ranges above this value is monitored.
Life Load . Threshold t [Protection Para / Condition Monitoring / Life Load]
1.00d 0.01d . . . 1000.00d P.1
An alarm is issued if the sum of operating times in current ranges above »I« exceeds this time threshold.
7.2.3
Life Load: Direct Controls
Life Load . Rst. Alarm [Operation / Reset]
Inactive Inactive, Active
╚═▷ Mode
P.1
Direct Command to reset the Alarm signal. This also resets the countdown timer »Time to Alarm« back to the setting
value »Threshold t«.
32 WIC1 WIC1-2.0-EN-REF
7 Statistics
7.2 Life Load – Load Current Histogram
